Seamless Steel Pipe & Welded Steel Pipe Manufacturer
  • Seamless Steel Pipe

    Maximum diameter: 36" (914.4mm) minimum diameter: 1/2" (21.3mm)
    Maximum thickness: 60mm mininmum thickness: 2.11mm
    SCH: SCH10,SCH20,STD,SCH40,SCH60,XS,SCH80,SCH100,SCH120,SCH160,XXS
    Seamless Steel Pipe
Seamless Carbon Steel Pipe+
API 5L GR.B, X42,X52,X60,X65 PSL1 & PSL2
Size range:  2" - 24"
Schedules: STD,SCH100,SCH120,SCH160,XXH
utilized for the water and petroleum industry to transport liquids or as platforms on off-shore rigs.

ASTM A53 GR.B, ASTM A106 GR.B
Size range:  1/8" - 26"
Schedules: SCH20, SCH30, SCH40, STD, SCH100, SCH120,SCH160,XXH
utilized for services ranging from structural supports to steam drum headers with temperature ranges up to 800°F

Manufacturing Process Of Seamless Carbon Steel Pipe
Billets and coils are delivered to the pipe mill ready to be made into carbon steel pipe. Depending on the capabilities of the pipe mill and the end use of the final product, the casts will be formed into pipe by means of four distinct different manufacturing.Seamless carbon steel pipe has, as its name implies, no longitudinal weld seam. It is, in essence, one solid homogeneous piece of steel. A solid billet is simply heated and then stretched over a series of mandrels until the pipe has achieved its desired diameter and wall thickness.
Seamless Stainless Steel Pipe+
Sizes: 1/8" - 36" +
Schedules: S/5s - XXS
Services: Bending - Cutting - Grooving - Polishing - Threading

Standard:
ASTM A312 Austenitic Stainless Steel Pipes for high-temperature and general corrosive service.
ASTM A213 for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A269 Austenitic Stainless Steel Tubes for General Service
ASTM A270 for Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubes

Grade: TP304,TP304L,TP304H,TP316,TP316L,TP316Ti,TP309,TP310S,TP321,TP321H, TP347, TP347H, TP405, TP410, TP430

Surface treatment: Industrial tubes Annealed and pickled, Sanitary tubes polished 180 grit, 240 grit, 400 grit
Boiler Tube+
Out diameter (OD) 10.2 - 139.7 mm
(from 26.9 mm manufactured as hot rolled)
WALL THICKNESS (WT) 0.5 - 16.0 mm
(from 2.6 mm manufactured as hot rolled)

ASTM A 210 – A&C Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes
ASTM A 213 - T-5, T-9, T-11, T-22, T-91 Specification for Seamless Alloy-Steel Boiler, Superheater and Heat Exchanger Tu
Seamless Mechanical Tube+
Size: OD: 10.3-762mm
WT: 6-35mm
Length: 5.8/6/11.8/12m

Standard: ASTM A53, ASTM A519, ASTM A500, ASTM A252, JIS G3441/G3445,EN 10210/10297

Seamless mechanical tubing
A-519

D.O.M mechanical tubing
A-513 T5
Seamless Galvanized Pipe+
Size Range ½”- 16” (15mm-400mm) ASTM A53 Gr. A/B

Method- Hot Dip Galvanizing



Size

O.D.

1/8”- 8” (5.15mm-219.1mm)

DN 6 - DN200

Max. → 24”(609.6mm)  DN 600

Wall

Thickness

0.4mm - 26mm

SCH20, SCH40, STD, XS, SCH80, SCH160, XXS

Length

Max. Length: 12m

Material

Q195 → SS330, ST37, ST42

Q235 → SS400, S235JR

Q345 → S355JR, SS500, ST52


Usage

1) Low Pressure Liquid, Water, Gas, Oil, Line pipe

2) Construction Site

3) Fence, Scaffold


Ends

1) Plain

2) Beveled

3) Thread

4) Chamfer

5) Groove


SurfaceTreatment

1) Bared

2) Black Painted

3) Galvanized

4) Oiled

5) Corrosion Resistant Coating,

Anti Corrosion Coating.

Seamless Heat Exchanger Tube+

ASTM A179 Standard require minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus

Out diameter:6.00 MM TO 101.00 MM

Thickess:0.85MM TO 12.7MM

Length:1.0 MTR TO 27.0 MTR


Applications include:
Shell & Tube Heat Exchangers
Feedwater Heaters
Condensers
Evaporators

Seamless Precision Tube+
OD:10-120MM
WT:0.5-5MM
LENGTH:4-8M
Seamless Hydraulic Tube+
Size: 4mm to 130mm outer diameter
Material:E355 (ST52.4),E235 (ST37.4)
Standard:DIN 2391/C (DIN EN 10305-1),DIN 2445/2 (DIN EN 10305-4)
Finishing:NBK (Phosphate and Normalized)
